No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
625 Vb-c (Vb-c=) Measurement 134 137 No 9 9 CFC CD DD
626 Vc-a (Vc-a=) Measurement 134 137 No 9 10 CFC CD DD
627 VN (VN =) Measurement 134 118 No 9 1 CFC CD DD
629 V1 (positive sequence) (V1 =) Measurement - - - - - CFC CD DD
630 V2 (negative sequence) (V2 =) Measurement - - - - - CFC CD DD
632 Vsync (synchronism) (Vsync =) Measurement - - - - - CFC CD DD
641 P (active power) (P =) Measurement 134 137 No 9 11 CFC CD DD
642 Q (reactive power) (Q =) Measurement 134 137 No 9 12 CFC CD DD
644 Frequency (Freq=) Measurement 134 137 No 9 13 CFC CD DD
645 S (apparent power) (S =) Measurement - - - - - CFC CD DD
661 Threshold of Restart Inhibit (Θ
REST. =)
Measurement - - - - - CFC CD DD
701 Resistive ground current in isol
systems (INs Real)
Measurement 134 137 No 9 15 CFC CD DD
702 Reactive ground current in isol
systems (INs Reac)
Measurement 134 137 No 9 16 CFC CD DD
805 Temperature of Rotor (ΘR/
ΘRtrip=)
Measurement - - - - - CFC CD DD
807 Thermal Overload (Θ/Θtrip =) Measurement - - - - - CFC CD DD
809 Time untill release of reclose-
blocking (T reclose=)
Measurement - - - - - CFC CD DD
830 INs Senstive Ground Fault Current
(INs =)
Measurement 134 118 No 9 3 CFC CD DD
831 3Io (zero sequence) (3Io =) Measurement - - - - - CFC CD DD
832 Vo (zero sequence) (Vo =) Measurement 134 118 No 9 2 CFC CD DD
833 I1 (positive sequence) Demand (I1
dmd=)
Demand meter - - - - - CFC CD DD
834 Active Power Demand (P dmd =) Demand meter - - - - - CFC CD DD
835 Reactive Power Demand (Q dmd
=)
Demand meter - - - - - CFC CD DD
836 Apparent Power Demand (S dmd
=)
Demand meter - - - - - CFC CD DD
837 I A Demand Minimum (IAdmdMin) Min/Max meter - - - - - CD DD
838 I A Demand Maximum
(IAdmdMax)
Min/Max meter - - - - - CD DD
839 I B Demand Minimum (IBdmdMin) Min/Max meter - - - - - CD DD
840 I B Demand Maximum
(IBdmdMax)
Min/Max meter - - - - - CD DD
841 I C Demand Minimum (ICdmdMin) Min/Max meter - - - - - CD DD
842 I C Demand Maximum
(ICdmdMax)
Min/Max meter - - - - - CD DD
Functions, Settings, Information
F.5 Measured Values
SIPROTEC 4, 7SJ62/64, Manual 715
C53000-G1140-C207-8, Edition 08.2016
