No. Information Type of
Informa-
tion
Comments
1837 51N picked up OUT 51N picked up
1838 51N TimeOut OUT 51N Time Out
1839 51N TRIP OUT 51N TRIP
1840 PhA InrushDet OUT Phase A inrush detection
1841 PhB InrushDet OUT Phase B inrush detection
1842 PhC InrushDet OUT Phase C inrush detection
1843 INRUSH X-BLK OUT Cross blk: PhX blocked PhY
1851 50-1 BLOCKED OUT 50-1 BLOCKED
1852 50-2 BLOCKED OUT 50-2 BLOCKED
1853 50N-1 BLOCKED OUT 50N-1 BLOCKED
1854 50N-2 BLOCKED OUT 50N-2 BLOCKED
1855 51 BLOCKED OUT 51 BLOCKED
1856 51N BLOCKED OUT 51N BLOCKED
1866 51 Disk Pickup OUT 51 Disk emulation Pickup
1867 51N Disk Pickup OUT 51N Disk emulation picked up
7551 50-1 InRushPU OUT 50-1 InRush picked up
7552 50N-1 InRushPU OUT 50N-1 InRush picked up
7553 51 InRushPU OUT 51 InRush picked up
7554 51N InRushPU OUT 51N InRush picked up
7556 InRush OFF OUT InRush OFF
7557 InRush BLK OUT InRush BLOCKED
7558 InRush Gnd Det OUT InRush Ground detected
7559 67-1 InRushPU OUT 67-1 InRush picked up
7560 67N-1 InRushPU OUT 67N-1 InRush picked up
7561 67-TOC InRushPU OUT 67-TOC InRush picked up
7562 67N-TOCInRushPU OUT 67N-TOC InRush picked up
7563 >BLOCK InRush SP >BLOCK InRush
7564 Gnd InRush PU OUT Ground InRush picked up
7565 Ia InRush PU OUT Phase A InRush picked up
7566 Ib InRush PU OUT Phase B InRush picked up
7567 Ic InRush PU OUT Phase C InRush picked up
10034 50-3 BLOCKED OUT 50-3 BLOCKED
10035 50N-3 BLOCKED OUT 50N-3 BLOCKED
Functions
2.2 Overcurrent Protection 50, 51, 50N, 51N
84 SIPROTEC 4, 7SJ62/64, Manual
C53000-G1140-C207-8, Edition 08.2016
