The red ACTIVE light should now be flashing regularly, and the screen displays:
7=PW 8=DECR FREQ 9=INCR FREQ 6=STOP
PULSE 10 ms @ 23920 Hz & 0 dB ATTN
Keypad Key Command Comments
[6]
STOP
7.10.2 Responder Trigger Sequence
Switch the ANT OFF, then ON and key in the following sequence of commands on the ANT keypad
([] indicates keypad keys):
Table 7-3 – Responder Trigger Sequence
Keypad Key Command Comments
[ON]
[2]
PULSE
[2]
SET
[2]
FREQ
[2], [3], [9], [2], [3]
Interrogation frequency for HPR
channel B33
[ENTER]
[4]
PW Pulse width set in ms
[1], [0], [ENTER]
[5]
TRIG
[2]
SET TRIG IN
[2]
REP PERIOD In ms
[7], [5], [0], [ENTER]
[1]
EXIT
[1]
EXIT
[1]
EXIT
[3]
SET TRIG OUT
[5]
START
