WSM6 Manual
Document Ref: UM-8270-000
Issue: A Rev 0
Section 3
14
Figure 3-12 – Type 8065-120-XM 1000m rated straight remote Transducer
1 4 holes M4 x15 deep, equi-spaced on a 58.0mm [2.28in] PCD (stainless steel inserts)
Tail Table (length L)
0.6m [2ft]
1.0m [3ft]
2.0m [6ft]
3.0m [10ft]
October 2011
