SECTION 10 – SPARES
10. Introduction
The following is a list of all available spares.
10.1 Type 8270 Wideband Sub-Mini 6G: Directional 4000 Metres
Table 10-1 – Type 8270 WSM6 Component Identification Table
Part No. Dwg No Description QTY
LOWER ENDCAP
641-3309 8070-010-01 Lower end cap assembly, 4000m no depth *
641-3334 8070-010-02 Lower end cap assembly, 4000m with depth *
317-2799 Bulkhead Connector Subconn MCBH5M AL/2-O 1
200-0081 Seal ‘O’ ring 200-008-5570 for pressure vent 2
200-8347 Seal ‘O’ ring 200-834-557 for endcap 2
641-2141 Blanking socket MCDC5F c/w locking sleeve 1
BATTERY
641-3264 7970-002-03 Nickel Metal Hydride Battery pack 1
TRANSDUCERS
641-3310 8070-005 Transducer end-cap – MF Directional 1
200-8347 Seal ‘O’ ring 200-834-557 for tdr end cap 2
ELECTRONICS
631-7596 8070-035-01 Rx/Tx PCB for 8070 (issue B) 1
631-7472 8070-036-01 CPU PCB (issue B) 1
631-7471 8070-039-01 End cap PCB (issue A) 1
850-8204 5550-020 Tx Coil Assembly 1
MECHANICAL PARTS
710-2763 8070-030 Housing 4000m 1
810-0854 7866-020 Housing sleeve 1
720-3034 7970-027 Chassis Plate 1
222-251A Screw-PH-SL-MSZP M2.5x6 (PCB to chassis) 6
230-175A Washer crinkle B/CU M2.5 (PCB to chassis) 6
110-0487
RM nylon cord 3mm (housing/endcap retainer),
210mm each
2
925-002C Silica gel bag, 1g 2
