10.2 Type 8271 Wideband Sub-Mini 6G: Omni-Directional 1000 Metres
Table 10-2 – Type 8271 Wideband Sub-Mini 6G: Omni-Directional 1000M
Part No. Dwg No Description QTY
LOWER ENDCAP
641-3335 8071-010-01 Lower end cap assembly, 1000m no depth *
641-3336 8071-010-02 Lower end cap assembly, 1000m with depth *
641-3450 8070-010-03 Lower end cap assembly, 100m with depth *
317-2799
Bulkhead Connector Subconn MCBH5M
AL/2O
1
200-0081 Seal ‘O’ ring 200-008-557 for pressure vent 2
200-8347 Seal ‘O’ ring 200-834-557 for end cap 2
641-2141 Blanking Socket MCDCF + locking sleeve 1
BATTERY
641-3264 7970-002-03 Nickel Metal Hydride Battery pack 1
TRANSDUCER
650-0927 Transducer spares kit – (incl. O rings) 1
750-0869 7656-076 Transducer guard 1
ELECTRONICS
631-7597 8070-035-02 Rx/Tx PCB for 8071 (issue B) 1
631-7472 8070-036-01 CPU PCB (issue B) 1
631-7471 8070-039-01 End cap PCB (issue A) 1
851-2025 5548-029 Tx Coil Assembly 1
MECHANICAL PARTS
710-2772 8071-016 Housing, 1000m 1
810-1260 8071-017 Housing sleeve 1
720-3034 7970-027 Chassis Plate 1
222-251A Screw-PH-SL-MSZP M2.5x6 (PCB to chassis) 6
230-175A Washer crinkle B/CU M2.5 (PCB to chassis) 6
110-0487
RM nylon cord 3mm
(housing/end cap retainer) 210mm each
2
925-002C Silica gel bag, 1g 2
