Sonardyne 8270 - Acoustic Command Test; Table 7-5 - Acoustic Command Test

WSM6 Manual
Document Ref: UM-8270-000
Issue: A Rev 0
Section 7
88 October 2011
7.10.4 Acoustic Command Test
Switch the ANT OFF, then ON and key in the following sequence of commands on the ANT keypad
([] indicates keypad keys):
Table 7-5 – Acoustic Command Test
Keypad Key Command Comments
[ON]
[3]
MULTI
[4]
NEW PAN
M [F], [ENTER]
Set Medium Frequency Band –
use the up/down keys for M
then 7 to select
[A],[D],[3],[3],[0],[1],[ENTER]
Set the command Address of
the WSM6
[E], N, [ENTER]
‘ENABLE’ command use
up/down arrow keys for N then
7 to select
The ANT will then display (if
working):
EN C: ENABLED E: 3
or (if not working):-
EN NO REPLY RECEIVED FROM COMPATT 3301
To repeat test, press [Enter]
