Sonardyne 8270 - APPENDIX B - FREQUENCY TABLES; B.1 HPR 300 Frequency Table

To Next Page

To Previous Page

WSM6 Manual

Document Ref: UM-8270-000

Issue: A Rev 0

Appendix B

122 October 2011

APPENDIX B – FREQUENCY TABLES

B Frequency Tables

B.1 HPR – 300 Frequency Table

ANT CHANNEL

REFERENCE

HPR CHANNEL

REFERENCE

INTERROGATION

FREQUENCY

FREQUENCY Hz

H1 01 20492 29762

H2 02 21552 30488

H3 03 22124 31250

H4 04 22727 31847

H5 05 23364 32468

H6 06 24038 27173

H7 07 24510 27777

H8 08 25000 28409

H9 09 26042 29070

H10

11 ( - Square)

21552 27173

H11

22 ( - Circle )

22727 28409

H12

33 ( - Delta)

23923 29762

H13 44 (X) 25126 31250

H14 55 (Y) 26455 32468
