Sonardyne 8270 - 3.3 Configuration Options

WSM6 Manual
Document Ref: UM-8270-000
Issue: A Rev 0
Section 3
16 October 2011
3.3 Configuration
The WSM6 is available in two different types; the 8270 Directional and the 8271 Omni-Directional.
Configurations depend on the requirements.
Table 3-1 – Type 8270 WSM6 Configuration Table
Type Number Transducer Depth Rating Depth Sensor Note
8270-000-01 Directional 4000m No
8270-000-03 Directional 4000m 4000m
8270-000-07 Directional 4000m 4000m
Female 8-way
connector wired
as Compatt 5
8270-000-08 Directional 4000m No
External release
voltage out
8270-000-11 Directional 4000m 4000m
Female 5-way
connector
Table 3-2 – Type 8271 WSM6 Configuration Table
Type Number Transducer Depth Rating Depth Sensor Note
8271-000-01 Omni-Directional 1000m No
8271-000-02 Omni-Directional 4000m No Special order
8271-000-03 Omni-Directional 1000m 1000m
8271-000-07 Omni-Directional 1000m 1000m
Remote
Transducer
