6-12
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-PC101/PC101E
A-7078-171-A CF-089 BOARD, COMPLETE (PC101)
A-7078-299-A CF-089 BOARD, COMPLETE (PC101E)
************************
(IC301 is not included in this complete board)
< CAPACITOR >
C101 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C102 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C104 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C105 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C201 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C202 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C203 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C204 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C205 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C206 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C207 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C208 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C209 1-127-692-11 CERAMIC CHIP 10uF 10% 6.3V
C210 1-127-692-11 CERAMIC CHIP 10uF 10% 6.3V
C211 1-127-692-11 CERAMIC CHIP 10uF 10% 6.3V
C212 1-127-692-11 CERAMIC CHIP 10uF 10% 6.3V
C214 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C215 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C301 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C303 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C304 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C306 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C307 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C309 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C311 1-113-992-11 TANTAL. CHIP 3.3uF 20% 35V
C312 1-165-897-11 TANTAL. CHIP 22uF 20% 10V
C313 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C314 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C315 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C317 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN101 1-794-404-21 CONNECTOR, BOARD TO BOARD 88P
CN102 1-794-410-11 CONNECTOR, FPC (ZIF) 27P
CN103 1-766-336-21 CONNECTOR, FFC/FPC 6P
CN104 1-766-340-21 CONNECTOR, FFC/FPC 10P
< DIODE >
D102 8-719-040-57 DIODE 02DZ8.2-TPH3
< FERRITE BEAD >
FB201 1-414-760-21 FERRITE 0UH
FB202 1-414-760-21 FERRITE 0UH
FB301 1-414-445-11 FERRITE 0UH
FB302 1-500-283-11 FERRITE 0uH (PC101)
FB302 1-216-805-11 METAL CHIP 47 5% 1/16W
(PC101E) (Note1)
< IC >
IC201 8-759-489-19 IC NJM3230V (TE2)
IC301 A-7031-367-A CCD BLOCK ASSY (CCD IMAGER) (Note2)
IC305 6-701-755-01 IC AD80017AJRURL
< COIL >
L102 1-414-771-91 INDUCTOR 10uH
L201 1-414-771-91 INDUCTOR 10uH
L301 1-469-528-91 INDUCTOR 100uH
L302 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q101 8-729-042-60 TRANSISTOR UN9114J- (K8).SO
Q301 8-729-037-74 TRANSISTOR UN9213J- (TX).SO
< RESISTOR >
R104 1-218-990-11 SHORT CHIP 0
R110 1-218-956-11 RES-CHIP 1.8K 5% 1/16W
R201 1-216-864-11 METAL CHIP 0 5% 1/16W
R202 1-216-864-11 METAL CHIP 0 5% 1/16W
R203 1-216-864-11 METAL CHIP 0 5% 1/16W
R204 1-216-864-11 METAL CHIP 0 5% 1/16W
R205 1-218-969-11 RES-CHIP 22K 5% 1/16W
R206 1-218-969-11 RES-CHIP 22K 5% 1/16W
R207 1-218-969-11 RES-CHIP 22K 5% 1/16W
R208 1-218-969-11 RES-CHIP 22K 5% 1/16W
R209 1-218-965-11 RES-CHIP 10K 5% 1/16W
R210 1-218-965-11 RES-CHIP 10K 5% 1/16W
R211 1-218-989-11 RES-CHIP 1M 5% 1/16W
R213 1-218-989-11 RES-CHIP 1M 5% 1/16W
R301 1-218-990-11 SHORT CHIP 0
R302 1-218-990-11 SHORT CHIP 0
R304 1-216-864-11 METAL CHIP 0 5% 1/16W
< SENSOR >
SE201 1-418-682-41 SENSOR, ANGULAR VELOCITY (PITCH)
SE202 1-418-682-21 SENSOR, ANGULAR VELOCITY (YAW)
FP-102 FLEXIBLE BOARD (Not supplied)
********************************
< DIODE >
D901 8-719-078-71 DIODE LN57A, SO (TAPE LED)
< HOLE ELEMENT >
H901 8-719-067-74 HOLE ELEMENT HW-105A-CDE-T (S REEL)
H902 8-719-067-74 HOLE ELEMENT HW-105A-CDE-T (T REEL)
< TRANSISTOR >
Q901 8-729-028-71 TRANSISTOR PN-166, SO (TAPE END)
Q902 8-729-028-71 TRANSISTOR PN-166, SO (TAPE TOP)
< SWITCH >
S903 1-572-288-11 SWITCH, PUSH (C.C.DOWN)
(Note 1) Resistor is mouted to the location where FB302
is printed.
(Note 2) Be sure to read “Precautions for Replacement
of CCD Imager” on page 4-8 when changing
the CCD imager
FP-102CF-089
