6-13
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-PC101/PC101E
A-7078-170-A ME-020 BOARD, COMPLETE
************************
< CAPACITOR >
C502 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C503 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C4401 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C4402 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C4403 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C4404 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C4405 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4406 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C4410 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4411 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C4412 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C4413 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C4414 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C4416 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C4417 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C4419 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4420 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4421 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4422 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C4423 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C4424 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C4425 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C4426 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C4427 1-127-988-81 CERAMIC CHIP 15000PF 10% 16V
C4428 1-164-938-11 CERAMIC CHIP 0.0015uF 10% 50V
C4429 1-164-938-11 CERAMIC CHIP 0.0015uF 10% 50V
C4430 1-127-988-81 CERAMIC CHIP 15000PF 10% 16V
C4432 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C4433 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C4434 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C4435 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C4437 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
< CONNECTOR >
CN401 1-766-336-21 CONNECTOR, FFC/FPC 6P
CN402 1-766-340-21 CONNECTOR, FFC/FPC 10P
CN404 1-794-404-21 CONNECTOR, BOARD TO BOARD 88P
CN502 1-691-354-21 CONNECTOR, FFC/FPC (ZIF) 16P
< DIODE >
D401 8-719-062-16 DIODE 01ZA8.2 (TPL3)
D402 8-719-062-16 DIODE 01ZA8.2 (TPL3)
D407 8-719-056-85 DIODE UDZSTE-178.2B
D501 8-719-084-93 DIODE NSCW215T-T39 (BACK LIGHT)
D502 8-719-084-93 DIODE NSCW215T-T39 (BACK LIGHT)
< FERRITE BEAD >
FB401 1-414-760-21 FERRITE 0uH
FB402 1-414-760-21 FERRITE 0uH
FB403 1-414-760-21 FERRITE 0uH
FB404 1-414-760-21 FERRITE 0uH
FB405 1-414-760-21 FERRITE 0uH
FB406 1-414-760-21 FERRITE 0uH
FB407 1-414-760-21 FERRITE 0uH
FB408 1-414-760-21 FERRITE 0uH
FB409 1-469-084-21 FERRITE 1mH
FB410 1-469-084-21 FERRITE 1mH
FB411 1-469-084-21 FERRITE 1mH
< IC >
IC501 8-759-581-11 IC NJM2125F (TE2)
IC4401 8-759-679-11 IC BH7870AKV-E2
< JACK >
J401 1-778-040-11 JACK, SMALL TYPE (AUDIO/VIDEO)
J402 1-691-737-41 JACK (SMALL TYPE) (MIC (PLUG IN POWER))
J403 1-793-995-11 JACK, SUPER SMALL TYPE (LANC)
< COIL >
L4401 1-469-528-91 INDUCTOR 100uH
< TRANSISTOR >
Q501 8-729-420-20 TRANSISTOR XN4312-TW
Q502 8-729-042-26 TRANSISTOR 2SB1462J-QR (K8).SO
Q503 8-729-427-83 TRANSISTOR XP6501- (TX).SO
< RESISTOR >
R401 1-216-864-11 METAL CHIP 0 5% 1/16W
R402 1-216-864-11 METAL CHIP 0 5% 1/16W
R501 1-208-939-11 METAL CHIP 150K 0.5% 1/16W
R502 1-208-719-11 METAL CHIP 33K 0.5% 1/16W
R505 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R508 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R509 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R4401 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R4402 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R4403 1-218-965-11 RES-CHIP 10K 5% 1/16W
R4404 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R4405 1-218-990-11 SHORT CHIP 0
R4406 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R4407 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R4408 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R4409 1-218-963-11 RES-CHIP 6.8K 5% 1/16W
R4410 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4411 1-218-953-11 RES-CHIP 1K 5% 1/16W
R4412 1-208-690-11 RES-CHIP 2K 5% 1/16W
R4413 1-208-690-11 RES-CHIP 2K 5% 1/16W
R4414 1-218-964-11 RES-CHIP 8.2K 5% 1/16W
R4415 1-220-198-11 RES-CHIP 20K 5% 1/16W
R4416 1-218-964-11 RES-CHIP 8.2K 5% 1/16W
R4417 1-220-198-11 RES-CHIP 20K 5% 1/16W
R4418 1-218-970-11 RES-CHIP 27K 5% 1/16W
R4419 1-218-970-11 RES-CHIP 27K 5% 1/16W
R4420 1-218-969-11 RES-CHIP 22K 5% 1/16W
R4421 1-218-969-11 RES-CHIP 22K 5% 1/16W
R4422 1-218-990-11 SHORT CHIP 0
R4423 1-218-965-11 RES-CHIP 10K 5% 1/16W
R4424 1-218-968-11 RES-CHIP 18K 5% 1/16W
R4425 1-218-977-11 RES-CHIP 100K 5% 1/16W
R4427 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
ME-020
