6-14
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-PC101/PC101E
< THERMISTOR >
TH501 1-810-811-11 THERMISTOR, NTC (1608)
< VARISTOR >
VDR401 1-803-974-21 VARISTOR, CHIP
VDR402 1-801-862-11 VARISTOR, CHIP
VDR403 1-801-862-11 VARISTOR, CHIP
VDR404 1-803-974-21 VARISTOR, CHIP
VDR405 1-803-974-21 VARISTOR, CHIP
A-7078-174-A MF-326 BOARD, COMPLETE
***********************
< PHOTO INTERRUPTER >
PH730 8-749-016-83 PHOTO COUPLER GP1S092HCPI
PH731 8-749-016-83 PHOTO COUPLER GP1S092HCPI
< RESISTOR >
R730 1-218-945-11 RES-CHIP 220 5% 1/16W
A-7078-173-A NS-014 BOARD, COMPLETE
**********************
< BATTERY >
BT001 1-756-128-11 BATTERY, LITHIUM (SECONDARY)
< DIODE >
D701 8-719-061-82 DIODE TLSU1002 (TPX1, SONY) (REC)
D702 8-719-078-78 DIODE DCZ2805 (NIGHT SHOT)
D703 8-719-078-78 DIODE DCZ2805 (NIGHT SHOT)
D704 8-719-016-74 DIODE 1SS352-TPH3
< IC >
IC701 8-742-221-00 HYB IC SBX3055-01
< RESISTOR >
R704 1-218-990-11 SHORT CHIP 0
A-7078-169-A PD-166 BOARD, COMPLETE
***********************
< CAPACITOR >
C802 1-113-988-11 TANTAL. CHIP 68uF 20% 4V
C803 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C806 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C807 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C808 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C809 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C810 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C811 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C812 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C814 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C815 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C816 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C817 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C818 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C819 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C820 1-164-872-11 CERAMIC CHIP 82PF 5% 50V
C821 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C822 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C823 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C824 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C825 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C826 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C827 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C828 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C829 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
C830 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C901 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C902 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C903 1-119-751-11 TANTAL. CHIP 22uF 20% 16V
C904 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C905 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C906 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
CN801 1-794-997-11 PIN, CONNECTOR 20P
* CN802 1-778-155-11 CONNECTOR, FFC/FPC (ZIF) 7P
CN803 1-794-766-21 CONNECTOR, FFC/FPC (LIF) 6P
* CN804 1-778-172-11 CONNECTOR, FFC/FPC (ZIF) 24P
< DIODE >
D801 8-719-073-01 DIODE MA111- (K8).S0
D802 8-719-084-47 DIODE 1SV290 (TPL3)
D803 8-719-050-42 DIODE RD3.3UM-T1B
D901 8-719-059-47 DIODE PG1111R-TR (STARTER)
< IC >
IC801 8-759-660-93 IC RB5P004AM1
IC802 8-752-409-15 IC CXD3516R-T4
< COIL >
L801 1-414-755-11 INDUCTOR 22uH
L802 1-414-754-11 INDUCTOR 10uH
L803 1-414-754-11 INDUCTOR 10uH
L804 1-412-943-11 INDUCTOR 2.2uH
L901 1-412-056-11 INDUCTOR 4.7uH
L902 1-414-757-11 INDUCTOR 100uH
< TRANSISTOR >
Q801 8-729-048-77 TRANSISTOR XP4313- (TX).SO
Q802 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8).SO
Q803 8-729-427-74 TRANSISTOR XP4601-TXE
Q804 8-729-037-74 TRANSISTOR UN9213J- (K8).SO
Q805 8-729-427-74 TRANSISTOR XP4601-TXE
Q806 8-729-041-23 TRANSISTOR NDS356AP
Q807 8-729-042-26 TRANSISTOR 2SB1462J-QR (K8).SO
Q901 8-729-042-72 TRANSISTOR UN9214J- (K8).SO
Q902 8-729-037-53 TRANSISTOR 2SA1832F-Y/GR (TPL3)
Q903 8-729-042-59 TRANSISTOR UN9112J- (K8).SO
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or eqivalent type.
ME-020 MF-326 NS-014 PD-166
