Sony DCR-PC101E - Page 145

6-15
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-PC101/PC101E
PD-166
< RESISTOR >
R801 1-218-965-11 RES-CHIP 10K 5% 1/16W
R802 1-218-990-11 SHORT CHIP 0
R804 1-218-990-11 SHORT CHIP 0
R806 1-218-985-11 RES-CHIP 470K 5% 1/16W
R807 1-218-985-11 RES-CHIP 470K 5% 1/16W
R808 1-218-977-11 RES-CHIP 100K 5% 1/16W
R809 1-218-967-11 RES-CHIP 15K 5% 1/16W
R810 1-218-958-11 RES-CHIP 2.7K 5% 1/16W
R811 1-218-973-11 RES-CHIP 47K 5% 1/16W
R812 1-218-975-11 RES-CHIP 68K 5% 1/16W
R813 1-218-969-11 RES-CHIP 22K 5% 1/16W
R814 1-218-975-11 RES-CHIP 68K 5% 1/16W
R815 1-218-989-11 RES-CHIP 1M 5% 1/16W
R816 1-218-977-11 RES-CHIP 100K 5% 1/16W
R817 1-218-977-11 RES-CHIP 100K 5% 1/16W
R818 1-216-864-11 METAL CHIP 0 5% 1/16W
R819 1-216-864-11 METAL CHIP 0 5% 1/16W
R820 1-208-635-11 RES-CHIP 10 5% 1/16W
R821 1-218-977-11 RES-CHIP 100K 5% 1/16W
R822 1-218-990-11 SHORT CHIP 0
R823 1-218-990-11 SHORT CHIP 0
R824 1-208-635-11 RES-CHIP 10 5% 1/16W
R825 1-218-977-11 RES-CHIP 100K 5% 1/16W
R826 1-208-635-11 RES-CHIP 10 5% 1/16W
R827 1-218-977-11 RES-CHIP 100K 5% 1/16W
R828 1-218-941-81 RES-CHIP 100 5% 1/16W
R829 1-218-965-11 RES-CHIP 10K 5% 1/16W
R830 1-218-985-11 RES-CHIP 470K 5% 1/16W
R831 1-218-990-11 SHORT CHIP 0
R832 1-218-965-11 RES-CHIP 10K 5% 1/16W
R834 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R835 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R836 1-208-957-11 RES-CHIP 820K 5% 1/16W
R837 1-218-979-11 RES-CHIP 150K 5% 1/16W
R838 1-218-969-11 RES-CHIP 22K 5% 1/16W
R901 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R902 1-218-953-11 RES-CHIP 1K 5% 1/16W
R903 1-218-941-81 RES-CHIP 100 5% 1/16W
Electrical parts list of the VC-284 board is
not shown.
Page 6-16 to 6-25 is not shown.
