The Edit window allows the configuration of the following settings:
Signal Type: Allows selection of the desired signal type. Available options include:
Disabled
CTCSS 1/3 Tones
CTCSS 1/10 Tones
Data Clocks
1PPS
Signal Output:
CTCSS 1/3 Tones (see also: "CTCSS 1/3 Tones" on page387)
CTCSS 1/10 Tones (see also: "CTCSS 1/10 Tones" on page387)
Data Clocks (see also: "Data Clock Signals" on page388)
1PPS (see also: "1PPS Duty Cycle" on page388)
Offset: Value (in nanoseconds) that can be used to adjust for cable delays or latencies.
Signature Control: Controls when the output will be present. For more information, see
"Signature Control" on page136.
819x Option 17 Mapping
To replicate settings used in Series 819x devices, use the following information to configure
option card no. 1204-14 for compatible CTCSS operation:
