All outputs are listed, displaying their current output states. For a listing of the states, see
"CTCSS Outputs: Edit Window" below, and "Alarm Outputs: Edit Window" on page386.
To view the settings of
one
of the Alarm Outputs or CTCSS Outputs, go to its Status window.
For instructions, see: "Viewing Input/Output Configuration Settings" on page329.
The Web UI list entry for this card is named: Simulcast.
Note: Alarm Output 0 through Alarm Output 3 are reserved by SecureSync. Num
bering for alarm outputs from the option card will begin at Alarm 4, which is
available on the DB-9 output, while Alarms 5 and 6 are assigned to the RJ-12 con
nector.
Figure 5-34: Simulcast Alarm Output Status window
CTCSS Outputs: Edit Window
To configure a CTCSS output, go to its Edit window. For instructions, see: "Configuring Option
Card Inputs/Outputs" on page330.
The Web UI list entry for this card is named: Simulcast.
384 SecureSync User Reference Guide
