You can also configure a notification alarm, see "Enabling/Disabling the BroadShield Ser-
vice" on page140.
BroadShield Web UIMonitoring
The BroadShield Web UI will also display real time signal status information, or a map status.
Note: If at any time you receive an error message Failed to connect to the unit, the
VersaSync Web UImay have timed out (see "Web UI Timeout" on page197).
Refresh your browser page to log back in.
To open the BroadShield user interface:
1.
Navigate to MONITORING > BroadShield. (If you cannot see the MONITORING button
in the Primary Navigation Bar of the HOMEscreen, this license is not present.)
2.
The embedded Broadshield Web UI will open, displaying the Dashboard and providing
access to the following panels:
DASHBOARD
The Dashboard panel displays up to 7 days of history data, and a real-time amplitude fre-
quency spectrum. The headline background color indicates the current jamming/spoofing
status: red= jamming or spoofing detected; green = no alarms at this time
