In the Debug 1 area, selecting Start opens the given valve, and selecting Stop closes it.
The valves are:
Valve
Location/Description
Valve
Location/Description
V_1
Viscometer Valve
V_5
Gutter Valve
V_2
Makeup Add Valve
V_6
Ink Add Valve
V_3
Printhead Bleed Valve
V_7
Printhead Ink Valve
V_4
Cleaning Valve
In the Debug 2 area, selecting Start activates the given part, and selecting Stop
deactivates it.
Select Close to close the Device settings.
