124 User Interface
2006792 Rev B – 200228
Mixing Tank
Select to view an approximation of current ink levels in the Mixing Tank. There are four
ink level sensors inside the Mixing Tank, represented by the graphic. The highest circle
filled with green indicates the current ink level.
Select Close to close the Mixing Tank settings.
Mixing Tank is too full
and may overflow
Ink is at normal operating level
(system will only fill to this point)
Lowest normal operating level
Ink is significantly below normal
operating level (will prompt
system to add ink)
