Operation 135
2006792 Rev B – 200228
4. Create the desired message
Add any combination of static and/or dynamic objects to create the message. Touch the
Message Area where the upper left corner of an object is to be placed, then select the
button for the kind of object to add.
Static objects include:
5. Move the objects into the desired positions using the Arrow buttons
a. Select the desired object to move
b. Use the arrow buttons to move the object into the desired position.
6. Make adjustments as needed
a. To edit the text in a text block, double-tap the text block. The text becomes red to
indicate that it can be edited. Tapping the Message Area outside of the text block
turns the text black to indicate that it is no longer editable.
b. If the text is too tall for the line (raster mode) into which it is supposed to fit, either:
Reduce the text size to fit inside the line by changing the font size at the top of
the screen, or
Enlarge the line height by selecting Raster Mode:
