158 Maintenance
2006792 Rev B – 200228
b. Continue to adjust the modulation value until the ink drop break-off point is as close
as possible to the midpoint in the Charge Electrode Tunnel.
5. Replace the Printhead Cover:
a. Slide the Printhead Cover back over the Printhead.
b. Secure the Printhead Cover in place by tightening the Cover Fastener.
Cover Fastener
Replacing the Printhead Cover
