Maintenance 171
2006792 Rev B – 200228
4. Prepare to replace the Storage Plugs:
During commissioning of the JetStream, plugs were removed from several components
of the system. These should have been stored in a clean, dry location where they could
be easily found. This manual suggested storing them in a ziploc plastic bag inside the
front of the JetStream Console, on the right side.
a. Retrieve the Storage Plugs.
5. Replace Ink and Makeup Plugs:
a. Open the Front Door of the JetStream by turning the knob and pulling the door open.
b. Locate the Ink and Makeup Nozzles inside the Ink and Makeup Container Bays,
toward the top.
To Next Page
