172 Maintenance
2006792 Rev B – 200228
c. Replace the Nozzle Plugs over the Ink and Makeup Nozzles by gently sliding the
plugs into place until they are snug.
d. Close the Front Door and secure it by turning the knob.
6. Replace the Vapor Outlet Tube Plug:
a. Open the Rear Door of the JetStream by unscrewing the top and bottom Fasteners
and pulling the door open.
b. Locate the Vapor Outlet Tube, which is the largest diameter unconnected plastic
tube extending from the top of the Mixing Tank.
c. Replace the plug on the loose end of the Vapor Outlet Tube by sliding it on until it is
snug.
d. Close the JetStream’s Rear Door and screw the Fasteners back into place.
7. Replace the two plugs inside the Printhead:
