DocID018909 Rev 11 479/1731

RM0090 Digital camera interface (DCMI)

479

Refer to Section: Memory map for the register boundary addresses.

0x14

DCMI_ICR

Reserved

LINE_ISC

VSYNC_ISC

ERR_ISC

OVR_ISC

FRAME_ISC

Reset value 00000

0x18

DCMI_ESCR

FEC LEC LSC FSC

Reset value 00000000000000000000000000000000

0x1C

DCMI_ESUR

FEU LEU LSU FSU

Reset value 00000000000000000000000000000000

0x20

DCMI_CWSTR

Reserve

VST[12:0

Reserved

HOFFCNT[13:0]

Reset value 0000000000000 00000000000000

0x24

DCMI_CWSIZ

Reserved

VLINE13:0]

Reserved

CAPCNT[13:0]

Reset value 00000000000000 00000000000000

0x28

DCMI_DR

Byte3 Byte2 Byte1 Byte0

Reset value 00000000000000000000000000000000

Table 87. DCMI register map and reset values (continued)
