System configuration controller (SYSCFG) RM0090

298/1731 DocID018909 Rev 11

9.3.2 SYSCFG peripheral mode configuration register (SYSCFG_PMC)

Address offset: 0x04

Reset value: 0x0000 0000

Bit 8 FB_MODE: Flash Bank mode selection

Set and cleared by software. This bit controls the Flash Bank 1/2 mapping.

0: Flash Bank 1 is mapped at 0x0800 0000 (and aliased at 0x0000 0000) and

Flash Bank 2 is mapped at 0x0810 0000 (and aliased at 0x0010 0000)

1: Flash Bank 2 is mapped at 0x0800 0000 (and aliased at 0x0000 0000) and

Flash Bank 1 is mapped at 0x0810 0000 (and aliased at 0x0010 0000)

Bits 7:3 Reserved, must be kept at reset value.

Bits 2:0 MEM_MODE: Memory mapping selection

Set and cleared by software. This bit controls the memory internal mapping at

address 0x0000 0000. After reset these bits take the value selected by the Boot

pins (except for FMC).

000: Main Flash memory mapped at 0x0000 0000

001: System Flash memory mapped at 0x0000 0000

010: FMC Bank1 (NOR/PSRAM 1 and 2) mapped at 0x0000 0000

011: Embedded SRAM (SRAM1) mapped at 0x0000 0000

100: FMC/SDRAM Bank 1 mapped at 0x0000 0000

Other configurations are reserved

Note: Refer to Section 2.3: Memory map for details about the memory mapping at

address 0x0000 0000.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

Reserved

MII_RMII

_SEL

Reserved

ADCxDC2

rw rw rw rw

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

Reserved

Bits 31:24 Reserved, must be kept at reset value.

Bit 23 MII_RMII_SEL: Ethernet PHY interface selection

Set and Cleared by software.These bits control the PHY interface for the

Ethernet MAC.

0: MII interface is selected

1: RMII PHY interface is selected

Note: This configuration must be done while the MAC is under reset and before

enabling the MAC clocks.
