DocID018909 Rev 11 75/1731

RM0090 Embedded Flash memory interface

112

Table 5. Flash module organization (STM32F40x and STM32F41x)

Block Name Block base addresses Size

Main memory

Sector 0 0x0800 0000 - 0x0800 3FFF 16 Kbytes

Sector 1 0x0800 4000 - 0x0800 7FFF 16 Kbytes

Sector 2 0x0800 8000 - 0x0800 BFFF 16 Kbytes

Sector 3 0x0800 C000 - 0x0800 FFFF 16 Kbytes

Sector 4 0x0801 0000 - 0x0801 FFFF 64 Kbytes

Sector 5 0x0802 0000 - 0x0803 FFFF 128 Kbytes

Sector 6 0x0804 0000 - 0x0805 FFFF 128 Kbytes

Sector 11 0x080E 0000 - 0x080F FFFF 128 Kbytes

System memory 0x1FFF 0000 - 0x1FFF 77FF 30 Kbytes

OTP area 0x1FFF 7800 - 0x1FFF 7A0F 528 bytes

Option bytes 0x1FFF C000 - 0x1FFF C00F 16 bytes
