DocID018909 Rev 11 503/1731
RM0090 LCD-TFT Controller (LTDC)
511
16.7.18 LTDC Layerx Pixel Format Configuration Register (LTDC_LxPFCR)
(where x=1..2)
This register defines the pixel format which is used for the stored data in the frame buffer of
a layer. The pixel data is read from the frame buffer and then transformed to the internal
format 8888 (ARGB).
Address offset: 0x94 + 0x80 x (Layerx -1), Layerx = 1 or 2
Reset value: 0x0000 0000
16.7.19 LTDC Layerx Constant Alpha Configuration Register (LTDC_LxCACR)
(where x=1..2)
This register defines the constant alpha value (divided by 255 by Hardware), which is used
in the alpha blending. Refer to LTDC_LxBFCR register.
Address offset: 0x98 + 0x80 x (Layerx -1), Layerx = 1 or 2
Reset value: (Layerx -1) 0x0000 00FF
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved
PF[2:0]
rw rw rw
Bits 31:3 Reserved, must be kept at reset value
Bits 2:0 PF[2:0]: Pixel Format
These bits configures the Pixel format
000: ARGB8888
001: RGB888
010: RGB565
011: ARGB1555
100: ARGB4444
101: L8 (8-Bit Luminance)
110: AL44 (4-Bit Alpha, 4-Bit Luminance)
111: AL88 (8-Bit Alpha, 8-Bit Luminance)
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Reserved
CONSTA[7:0]
rw rw rw rw rw rw rw rw
