STOBER 8 | Connection
12/2018 | ID 442537.05
109
Cable requirements
Feature All sizes
Max. cable length 50m, shielded
Tab. 118: Cable length [m]
8.6.2 RI6
8.6.2.1 Overview
RI6
2
9
11
10
12
13
15
14
16
X101
18
17
19
1
1
3
2
4
5
7
6
8
X100
3
5
S2
S1
S3
HTL
TTL
4
Fig.22: Connection overview for the RI6 terminal module
1 X100: AE1 – AE2, AA1 – AA2
2 X101: BE1 – BE5, BA1 – BA2
3 X120: Encoder connection
4 3 sliders for the HTL/TTL level conversion
5 X140: Encoder connection
