STOBER 5 | Technical data
12/2018 | ID 442537.05
21
Designation Value in example Meaning
Types SD6A06TEX Device type according to type designation
Date 1712 Production week in format YYWW, in the example
shown here year 2017, week 12
S/N 7000457 Serial number
Input voltage 3 × 400V
AC
50Hz
UL: 3 × 480V
AC
50–60Hz
Input voltage
Input current 3 × 4.0A Input current
Output data 0 to 460V
DC
0 to 700Hz
@8kHz: 3 × 4.5A
Output voltage
Output frequency
Output current for 8kHz clock frequency
Protection class IP20 Protection class
Tab. 6: Meaning of the specifications on the SD6 nameplate
Information
UL and cUL certified devices with the corresponding test symbol meet the requirements of
standards UL 508C and UL 840.
5.1.3 Material version
On the side of the drive controller next to the nameplate, there is another sticker with the MV
and serial number.
Fig.2: Sticker with MV and serial number
Designation Value in example Meaning
MV MV0000052345 MV number
SN SN: 600154723 Serial number
— SD6A06TEX Device type according to type designation
— 550007951/000100 Order number / order item
Tab. 7: Meaning of the specifications on the sticker
