12.3 Replacing the drive controller
DANGER!
Electrical voltage! Risk of fatal injury due to electric shock!
▪ Always switch off all power supply voltage before working on the devices!
▪ Note the discharge time of the DC link capacitors in the general technical data. You can
only determine the absence of voltage after this time period.
ATTENTION!
Loss of absolute position!
The absolute position in the encoder is lost if the encoder cable is disconnected from the AES
battery module.
▪ Do not disconnect the encoder cable from the AES during service work! Disconnect the
AES from the drive controller.
CAUTION!
Risk of damage to property due to electrostatic discharge!
Take appropriate measures when handling exposed circuit boards, e.g. wearing ESD-safe
clothing.
Do not touch contact surfaces.
Information
The safety module is a permanently integrated component in the drive controller where any
design, technical and electrical modifications are prohibited!
Any removal of the safety module from the drive controller as well as any attempt at repair or
replacement is prohibited. The drive controller and safety module do not require maintenance.
Tool and material
You will need:
§ Tool for loosening and tightening the fastening screws
Requirements and replacement
ü
Drive controllers of the same series and same power can be replaced interchangeably.
ü
The hardware and firmware of the drive controller being installed have the same or a newer
version than the drive controller being replaced. You can find information about firmware
updates in the chapter Replacing or updating the firmware [}149].
ü
The Paramodul is present in the drive controller being replaced; the original project is
stored on the Paramodul.
