Page #45 background imageLoading...
Page #45 background image
STOBER 7 | Installation
12/2018 | ID 442537.05
45
7.6 Installing the communication module
In order to connect EtherCAT, CANopen or PROFINET, you need an EC6, CA6 or PN6
communication module. The communication module is installed in the upper slot. Installation is
identical for all communication modules.
DANGER!
Electrical voltage! Risk of fatal injury due to electric shock!
Always switch off all power supply voltage before working on the devices!
Note the discharge time of the DC link capacitors in the general technical data. You can
only determine the absence of voltage after this time period.
CAUTION!
Risk of damage to property due to electrostatic discharge!
Take appropriate measures when handling exposed circuit boards, e.g. wearing ESD-safe
clothing.
Do not touch contact surfaces.
Tool and material
You will need:
§ A TORX screwdriver TX10
§ The cover and screws included with the communication module
Installation
1. Unscrew the fastening screw of the dummy cover on top of the drive controller and remove
the cover.
2. Slide the communication module on the guide rails into the drive controller.
3. Press on the module in order to push the pin contacts into the box header.
4. Set the tabs of the cover included with the communication module in front in the notch at an
angle.
5. Place the cover on the drive controller so that the tabs lie under the edge.
6. Attach the cover using both screws.
