STOBER 5 | Technical data
12/2018 | ID 442537.05
19
5 Technical data
This chapter contains the technical data for the SD6 drive controller, the DC link connection, the
safety technology and the brakes. Additional technical data on the drive controller and
accessories can be found in the SD6 drive controller manual; see the chapter Detailed
information [}161].
5.1 Drive controllers
The following chapters contain specifications for the electrical data, dimensions and weight of
the drive controller.
5.1.1 General technical data
The following specifications apply to all drive controller types.
Device features
Protection class of the device IP20
Protection class of the installation
space
At least IP54
Radio interference suppression Integrated line filter in accordance with EN 61800-3:2012,
interference emission class C3
Overvoltage category III in accordance with EN 61800-5-1:2008
Test symbols
Tab. 2: Device features
Transport and storage conditions
Storage/
transport temperature
−20°C to +70°C
Maximum change: 20K/h
Relative humidity Maximum relative humidity 85%, non-condensing
Vibration (transport) in accordance
with DIN EN60068-2-6
5Hz ≤ f ≤ 9Hz: 3.5mm
9Hz ≤ f ≤ 200Hz: 10m/s²
200Hz ≤ f ≤ 500Hz: 15m/s²
Tab. 3: Transport and storage conditions
Operating conditions
Surrounding temperature during
operation
0°C to 45°C with nominal data
45°C to 55°C with derating −2.5%/K
Relative humidity Maximum relative humidity 85%, non-condensing
Installation altitude 0m to 1000m above sea level without restrictions
1000m to 2000m above sea level with −1.5%/100m derating
Pollution degree Pollution degree 2 in accordance with EN 50178
Ventilation Installed fan
Vibration (operation) in accordance
with DIN EN 60068-2-6
5Hz ≤ f ≤ 9Hz: 0.35mm
9Hz ≤ f ≤ 200Hz: 1m/s²
Tab. 4: Operating conditions
