7.8 Installing the drive controller without a rear section
module
This chapter describes the installation of the SD6 drive controller without a rear section module.
If you would like to connect SD6 drive controllers in the DC link or insert rear section braking
resistors, you must mount the required rear section modules and then build the appropriate
drive controllers over them.
DANGER!
Electrical voltage! Risk of fatal injury due to electric shock!
▪ Always switch off all power supply voltage before working on the devices!
▪ Note the discharge time of the DC link capacitors in the general technical data. You can
only determine the absence of voltage after this time period.
Information
Note that drive controllers in storage require reforming each year or before commissioning at
the latest.
Tools and material
You will need:
§ Fastening screws
§ Tool for tightening the fastening screws
Requirements and installation
Perform the following steps for each drive controller within the group and in the specified order.
ü
In accordance with the drilling diagram, taking into consideration the various device
dimensions, you have made threaded holes for the threaded bolts on the mounting plate at
the mounting position.
ü
The mounting plate has been cleaned (free of oil, grease and swarf).
1. If present, install the communication module; see the chapter Installing the communication
module [}45].
2. If present, install the terminal module; see the chapter Installing the terminal module [}46].
3. Size 3: Mount the EM6A3 EMC shroud; see the chapter Attaching the EMC shroud [}58].
4. Fasten the top of the drive controller on the mounting plate.
5. Sizes 0 to 2: Mount the EM6A0 EMC shroud; see the chapter Attaching the EMC shroud
[}58].
6. Fasten the bottom of the drive controller on the mounting plate.
7. Connect the grounding conductor to the ground bolt. Note the instructions and
requirements in the chapter Housing grounding [}65].
ð The installation is completed. In the next step, connect the drive controller.
