STOBER 13 | Appendix
12/2018 | ID 442537.05
157
13.1.13 ISPC 16 -ST-10,16
Feature Line type Value
Contact spacing — 10.16mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
55A/66A/66A
Max. conductor cross-section Flexible without end sleeve 16.0mm²
Flexible with end sleeve without plastic collar 16.0mm²
Flexible with end sleeve with plastic collar 10.0mm²
2 conductors, flexible, with double end sleeve
with plastic collar
4.0mm²
AWG according to UL/CSA 4
Min. conductor cross-section Flexible without end sleeve 0.75mm²
Flexible with end sleeve without plastic collar 0.75mm²
Flexible with end sleeve with plastic collar 0.75mm²
2 conductors, flexible, with double end sleeve
with plastic collar
0.75mm²
AWG according to UL/CSA 20
Insulation stripping length — 18mm
Tightening torque — —
Tab. 175: SPC 16 -ST-10,16 specification
13.1.14 MKDSP 25 -15,00
Feature Line type Value
Contact spacing — 15.0mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
125A/115A/115A
Max. conductor cross-section Flexible without end sleeve 35.0mm²
Flexible with end sleeve without plastic collar 35.0mm²
Flexible with end sleeve with plastic collar 35.0mm²
2 conductors, flexible, with double end sleeve
with plastic collar
16.0mm²
AWG according to UL/CSA 2
Min. conductor cross-section Flexible without end sleeve 0.5mm²
Flexible with end sleeve without plastic collar 1.0mm²
Flexible with end sleeve with plastic collar 1.5mm²
2 conductors, flexible, with double end sleeve
with plastic collar
0.5mm²
AWG according to UL/CSA 20
Insulation stripping length — 18mm
Tightening torque Conductor cross-sections ≤ 25.0mm² 2.5Nm
Conductor cross-sections > 25.0mm² 4.5Nm
Tab. 176: MKDSP 25 -15,00 specification
