STOBER 8 | Connection
12/2018 | ID 442537.05
81
Cable requirements
Feature All sizes
Max. cable length 100m, shielded
Tab. 60: Cable length [m]
Information
To ensure proper functionality, we recommend using cables from STOBER that are matched to
the complete system. In case of use of unsuitable connection cables, we reserve the right to
reject claims under the warranty.
8.4.7 X5: Brake – Actuation
The brake is connected to X5.
Information
Note that brakes from other manufacturers may be connected only after consultation with
STOBER.
Controllable brakes
Note the technical data of the brakes controllable at X5; see the chapter X5 [}35].
Information
In the parameters F93 and F100, you can set whether the brake is connected directly or
indirectly and whether brake monitoring is deactivated.
Pin Designation Function
5 | 6
5 1BD1 Brake actuation
6 1BD2 Reference potential
Tab. 61: X5 connection description
Connecting wiring
For connecting wiring, observe the terminal specifications in the chapter BFL 5.08HC 180 SN
[}153].
Cable requirements
Feature All sizes
Max. cable length 100m
Tab. 62: Cable length [m]
