Stober SD6 Series User Manual

STOBER 13 | Appendix
12/2018 | ID 442537.05
151
Safety module
Type X2, X5, X6
32
X12
ST6
BFL 5.08HC 180 SN [}153] BCF 3,81 180 SN [}152]
Tab. 160: Terminal specifications of the ST6 safety module
Type X2, X5, X7, X8
33
X14, X15
SE6
BFL 5.08HC 180 SN [}153] DFMC 1.5 -ST-3.5 [}154]
Tab. 161: Terminal specifications of the SE6 safety module
Terminal modules
Type X100, X101 X102, X103
XI6
FK-MCP 1,5 -ST-3,5 [}152] FMC 1,5 -ST-3,5 [}151]
RI6 —
IO6 —
Tab. 162: Terminal specifications for the terminal modules
Encoder adapter box
Type X302, X305, X306 X303
LA6
FK-MCP 1,5 -ST-3,5 [}152] BFL 5.08HC 180 SN [}153]
Tab. 163: Terminal specifications for the encoder adapter box
13.1.2 FMC 1,5 -ST-3,5
Feature Line type Value
Contact spacing — 3.5mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA: 8A
Max. conductor cross-section Flexible without end sleeve 1.5mm²
Flexible with end sleeve without plastic collar 1.5mm²
Flexible with end sleeve with plastic collar 0.75mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 16
Min. conductor cross-section Flexible without end sleeve 0.2mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 24
Insulation stripping length — 10mm
Tightening torque — —
Tab. 164: FMC 1,5 -ST-3,5 specification
32
In addition to connections for the safety technology, the functional connections X2, X5, X6 are also lo-
cated on the ST6 safety module (not related to the safety technology).
33
In addition to connections for the safety technology, the connections X2 and X5 are also located on the
SE6 safety module (not related to the safety technology).
