Stober SD6 Series User Manual

13 | Appendix STOBER
154
12/2018 | ID 442537.05
13.1.7 DFMC 1.5 -ST-3.5
Feature Line type Value
Contact spacing — 3.5mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA: 8A
Max. conductor cross-section Flexible without end sleeve 1.5mm²
Flexible with end sleeve without plastic collar 1.5mm²
Flexible with end sleeve with plastic collar 0.75mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 16
Min. conductor cross-section Flexible without end sleeve 0.2mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 24
Insulation stripping length — 10mm
Tightening torque — —
Tab. 169: Specification for DFMC 1.5 -ST-3.5
13.1.8 GFKC 2,5 -ST-7,62
Feature Line type Value
Contact spacing — 7.62mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
12A/10A/10A
Max. conductor cross-section Flexible without end sleeve 2.5mm²
Flexible with end sleeve without plastic collar 2.5mm²
Flexible with end sleeve with plastic collar 2.5mm²
2 conductors, flexible, with double end sleeve
with plastic collar
1.0mm²
AWG according to UL/CSA 12
Min. conductor cross-section Flexible without end sleeve 0.2mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve
with plastic collar
0.5mm²
AWG according to UL/CSA 26/24
Insulation stripping length — 10mm
Tightening torque — —
Tab. 170: GFKC 2,5 -ST-7,62 specification
