13 | Appendix STOBER
152
12/2018 | ID 442537.05
13.1.3 FK-MCP 1,5 -ST-3,5
Feature Line type Value
Contact spacing — 3.5mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA: 8A
Max. conductor cross-section Flexible without end sleeve 1.5mm²
Flexible with end sleeve without plastic collar 1.5mm²
Flexible with end sleeve with plastic collar 0.5mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 16
Min. conductor cross-section Flexible without end sleeve 0.14mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 28
Insulation stripping length — 9mm
Tightening torque — —
Tab. 165: FK-MCP 1,5 -ST-3,5 specification
13.1.4 BCF 3,81 180 SN
Feature Line type Value
Contact spacing — 3.81mm
Nominal current at ϑ
amb
= 40°C — CE/UL/CSA:
16A/10A/11A
Max. conductor cross-section Flexible without end sleeve 1.5mm²
Flexible with end sleeve without plastic collar 1.0mm²
Flexible with end sleeve with plastic collar 1.0mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 16
Min. conductor cross-section Flexible without end sleeve 0.14mm²
Flexible with end sleeve without plastic collar 0.25mm²
Flexible with end sleeve with plastic collar 0.25mm²
2 conductors, flexible, with double end sleeve
with plastic collar
—
AWG according to UL/CSA 26
Insulation stripping length — 10mm
Tightening torque — —
Tab. 166: BCF 3,81 180 SN BK specification
