2.6.2 Markup of text elements
Certain elements of the continuous text are distinguished as follows.
Quick DC-Link module Words or expressions with a special meaning
Detailed information
Internal cross-reference
http://www.stoeber.de External cross-reference
Software and display indicators
The following formatting is used to identify the various information content of elements
referenced by the software interface or the drive controller display, as well as any user entries.
Main menu
Settings
Window names, dialog names, page names or buttons,
combined proper nouns, functions referenced by the interface
Select
Referencing method A
Predefined entry
Save your
<own IP address>
User-defined entry
EVENT 52:
COMMUNICATION
Display indicators (status, messages, warnings, faults) for
status information referenced by the interface
Keyboard shortcuts and command sequences or paths are represented as follows.
[CTRL], [CTRL] +
[S]
Key, shortcut
Table > Insert table
Navigation to menus/submenus (path specification)
Buttons
The buttons of the drive controller are depicted as follows in .
[OK]
Interpretation of parameter identification
Parameter identification consists of the following elements, where short forms are also possible,
i.e. only specifying a coordinate or the combination of coordinate and name.
E50 Drive controllers V0
Coordinate Name Version
