8 | Connection STOBER
86
12/2018 | ID 442537.05
8.4.12 X11: 24V supply
The connection of 24V
DC
to X11 is required for the power supply of the control unit.
ATTENTION!
Device damage due to overload!
If the 24 V
DC
power supply is looped to multiple devices over the terminal, the terminal may be
damaged by a current that is too high.
▪ Make sure that the current over the terminal does not exceed the value 15A (UL: 10A).
Electrical data All types
U
1CU
24V
DC
, +20%/−15%
I
1maxCU
1.5 A
Tab. 76: Control unit electrical data
Pin Designation Function
1 | 3
2 | 4
1 + 24V
DC
supply for the control unit; bridged in
the terminal; design in accordance with EN
60204: PELV, secondary grounded,
recommended fuse protection: max. 15AT
8
2
3 − Reference potential for +24V
DC
, bridged in
the terminal
4
Tab. 77: X11 connection description
Information
The device may not be connected to a DC supply grid. Instead, supply it over a local 24 V
DC
power supply.
Connecting wiring
For connecting wiring, observe the terminal specifications in the chapter BLDF 5.08 180 SN
[}153].
Cable requirements
Feature All sizes
Max. cable length 30m
Tab. 78: Cable length [m]
8
For UL-compliance, use of a 10A fuse (time delay) is required. Be sure that the fuse meets certification
requirements for DC voltage in accordance with UL 248.
