3-14 Instruments and controls
reaches near the middle of the range.
Engine operation is optimum with the
engine coolant at this temperature range
and high revving operation when the
engine is not warmed up enough should
be avoided.
CAUTION
If the pointer exceeds the normal
operating range, safely stop the
vehicle as soon as possible.
Refer to “
s09aeEngine overheating”
F9-11.
& ECO gauge (if equipped)
S03AD12
The unit displayed varies depending on
the destination.
The ECO gauge shows the difference
between the average rate of fuel con-
sumption since the trip meter was last
reset and the current rate of fuel con-
sumption.
The ECO gauge indicates the current fuel
efficiency as shown in the following chart.
Displayed unit
Needle pointing
“+” side “-” side
MPG
Better Poorer
km/l
l/100km Poorer
Better
NOTE
. The ECO gauge shows only an
approximate indication of fuel effi-
ciency.
. After resetting the trip meter, the
average rate of fuel consumption is not
shown until driving 1 km (0.6 mile).
Until that time, the ECO gauge does not
operate.
Warning and indicator lights
S03AE
Several of the warning and indicator lights
illuminate when the ignition switch is
initially turned to the “ON” position. This
permits checking the operation of the
bulbs.
Apply the parking brake and turn the
ignition switch to the “ON” position. For
the system check, the following lights
illuminate and then turn off after several
seconds or after the engine has started.
: Seatbelt warning light (if equipped)
(The seatbelt warning light turns off
only when the driver fastens the
seatbelt.)
: Front passenger’s seatbelt warning
light (Australia models only)
(The seatbelt warning light turns off
only when the front seat passenger
fastens the seatbelt.)
: AWD warning light (AT models)
: Power steering warning light
(if equipped)
: SRS airbag system warning light
: Malfunction indicator lamp
(Check Engine light)
