4-12 Climate control
& Replacing an air filter
S04AE01
1. Remove the glove box.
(1) Open the glove box.
(2) Remove the damper shaft from the
glove box.
(3) While pushing the stoppers on
both sides of the glove box, swing
the glove box down and remove it.
1) Caution label
A) CAUTION
B) THIS VEHICLE IS EQUIPPED WITH A
VENTILATION AIR FILTER WHICH
COLLECTS DUST, POLLEN etc.
C) TO ENSURE VENTILATION, A/C, HEAT-
ING AND DEFROSTING PERFOR-
MANCE, PLEASE REPLACE FILTER
PERIODICALLY ACCORDING TO
OWNER’S MANUAL.
2. Carefully read the caution label that is
attached on the trim cover.
3. Remove the air filter.
To Next Page
