Fuse
panel
Fuse
rating
Circuit
15 Empty
(FWD connector for
AWD AT models)
16 10A
. Illumination
17 15A
. Seat heaters
18 10A
. Back-up light
19 Empty
20 10A
. Accessory power outlet
(instrument panel)
21 7.5A
. Starter relay
22 15A
. Air conditioner
. Rear window defogger
relay coil
23 15A
. Rear wiper
. Rear window washer
24 15A
. Audio unit
. Clock
25 15A
. SRS airbag system
26 7.5A
. Power window relay
. Radiator main fan relay
27 15A
. Blower fan
28 15A
. Blower fan
29 15A
. Fog light
30 30A
. Front wiper
Fuse
panel
Fuse
rating
Circuit
31 7.5A
. Auto air conditioner unit
. Integrated unit
32 Empty
33 7.5A
. ABS/Vehicle Dynamics
Control unit
Specifications
12-15
– CONTINUED –
