1-36 Seat, seatbelt and SRS airbags
anchorage and tighten the top tether. For
additional instructions, refer to “
s01ag09Top
tether anchorages” F1-36.
For further information about the child
restraint system, refer to the instruction
manual supplied by the child restraint
system manufacturer.
NOTE
Before installing a child restraint sys-
tem, ask the manufacturer of the sys-
tem to confirm that it is one approved
for your vehicle.
& Top tether anchorages
S01AG09
Your vehicle is provided with two or three
top tether anchorages so that a child
restraint system having a top tether can
be install ed in the rear seat. When
installing a child restraint system using
top tether, proceed as follows, while
observing the instructions by the child
restraint system manufacturer.
Since a top tether can provide additional
stability by offering another connection
between a child restraint system and the
vehicle, we recommend that you use a top
tether whenever one is required or avail-
able.
! Anchorage location
S01AG0901
1) For right seat
2) For center seat (for Australia models)
3) For left seat
There is an anchorage located on the rear
edge of the ceiling above each seating
position.
! To hook the top tether
S01AG0902
CAUTION
Always remove the head restraint
when mounting a child restra int
system with a top tether. Failure to
do so may prevent the top tether
from being fastened tightly.
1. Remove the head restraint at the
seating position where the child restraint
system has been installed with the ISOFIX
anchor bars or seatbelt; lift up the head
restraint while pressing the release button.
Store the head restraint in the cargo area.
Avoid placing the head restraint in the
passenger compartment to prevent it from
