4-2 Climate control
Ventilator control
S04AF
& Center ventilators
S04AF01
Move the tab to adjust the flow direction.
& Side ventilators
S04AF02
1) Open
2) Close
3) Thumb-wheel
Move the tab to adjust the flow direction.
To open or close the ventilator, turn the
thumb-wheel up or down.
Climate control panel
S04AG
Type A panel is used for the manual
climate control system and for the heater
system without air conditioner.
Refer to “
s04abManual climate control” F4-8.
Type B and C panels are used for the
automatic climate control systems.
Refer to “
s04acAutomatic climate control
system (type B and C)” F4-6 for auto-
matic operation.
Refer to “
s04abManual climate control” F4-8
for manual operation.
