. When the warning light is on (and
the brake system warning light is
off), the ABS function shuts
down. However, the conventional
brake system continues to oper-
ate normally.
The ABS warning light illuminates to-
gether with the brake system warning light
if the EBD system malfunctions. For
further details of the EBD system mal-
function warning, refer to “
s03ae10Brake sys-
tem warning light” F3-22.
NOTE
If the warning light behaves as follows,
the ABS system may be considered
normal.
. The warning light illuminates right
after the engine is started but turns off
immediately, remaining off.
. The warning light remain s illumi-
nated after the engine has been started,
but it turns off when the vehicle speed
reaches approximately 12 km/h (8
mph).
. The warning light illuminates during
driving, but it turns off immediately and
remains off.
When driving with an insufficient battery
voltage such as when the engine is jump
started, the ABS warning light may illumi-
nate. This is due to the low battery voltage
and does not indicate a malfunction.
When the battery becomes fully charged,
the light will turn off.
& Vehicle Dynamics
Control warning light/
Vehicle Dynamics Con-
trol OFF indicator light
S03AE15
This warning light functions to indicate
malfunctions in the Vehicle Dynamics
Control system as well as to indicate that
the Vehicle Dynamics Control system has
been deactivated.
It illuminates in the event of a malfunction
in the system and is on when the system
is not operating.
! Vehicle Dynamics Control warning
light
S03AE1501
CAUTION
The Vehicle Dynamics Control sys-
tem provides its ABS control
through the electrical circuit of the
ABS system. Accordingly, if the ABS
is inoperative, the Vehicle Dynamics
Control system becomes unable to
provide ABS control. As a result, the
Vehicle Dynamics Control system
also becomes inoperative, causing
the warning light to illuminate.
Though both the Vehicle Dynamics
Control and ABS systems are inop-
erative in this case, the ordinary
functions of the brake system are
still available. You will be safe while
driving with this condition, but drive
carefully. We recommend that you
have your vehicle checked at a
SUBARU dealer as soon as possi-
ble.
NOTE
. If the electrical circuit of the Vehicle
Dynamics Control system itself mal-
functions, only this warning light illu-
minates. At this time, the ABS (Anti-
lock Brake System) remains fully op-
erational.
. The warning light illuminates when
the electronic control system of the
ABS/Vehicle Dynamics Control system
malfunctions.
The Vehicle Dynamics Control system is
probably inoperative under any of the
following conditions. We recommend that
you have your vehicle checke d at a
SUBARU dealer immediately.
. The warning light does not illuminate
when the ignition switch is turned to the
“ON” position.
Instruments and controls 3-21
– CONTINUED –
