sure to jack up all four wheels or use
free rollers.
For maintenance and inspection per-
formed on AWD 4-speed A T models
which requires a running engine and the
front wheels turning (for example, when
they are jacked up, driven on rollers, or
tested by a brake tester), deactivate the
AWD capability of the vehicle as follows.
1. Turn the ignition switch to the “LOCK”/
“OFF” position.
2. Pull any one spare fuse out of the
spare fuse holder in the engine compart-
ment. The spare fuse holder is located at
the back side of the fuse holder cover. You
may pick up any one of the fuses in the
spare fuse holder.
1) Spare fuse
2) FWD connector
Type A and B combination meter
Type D combination meter
3. Put a spare fuse inside the FWD
connector located at the fuse panel in
the cabin and confirm that the All-Wheel
Drive warning light “
” illuminates. The
All-Wheel-Drive capability of the vehicle
has now been deactivated.
Always use reliable blocks to prevent the
vehicle from moving. Never race the
engine or brake suddenly.
Maintenance and service 11-9
– CONTINUED –
11
