You will find the marks “ ” on the cover at
the bottom of the rear seat seatbacks.
These marks indicate the positions of the
ISOFIX anchor bars.
1. Use the “ ” marks to locate the two
anchor bars for the position where you
want to install the child restraint system.
2. While following the instructions sup-
plied by the child restraint system manu-
facturer, connect the connectors of the
child restraint system to the anchor bars.
When the connectors are fastened, make
sure that the adjacent seatbelts are not
caught.
3. Before seating a child in the child
restraint system, try to move it back and
forth and right and left to check that it is
firmly secured.
If the child restraint system requires a top
tether, latch the hook onto the top tether
Seat, seatbelt and SRS airbags 1-35
– CONTINUED –
