Predefined User Configurations
Page C-6 Instruction Manual: evolution 5000 E5710 and E5720 Encoder
ST.TM.E10074.1
Module Parameter Default Value
Language (R) English
Clip Level 18 dB
PID 0x100 - 0x105
Termination 20 kΩ
Auto Lip Sync On
Lip Sync Delay 111 ms
Lip Sync Offset 0 ms
Audio (Dolby Digital (AC-3)): Bit-rate 192 kbit/s
Bit-stream Mode Complete Main
Coding Mode 2/0 (Stereo)
Copyright Off
Original Off
Dolby Surround Mode Not Indicated
Dialogue Normalisation -27 dB
Audio Production Information Off
Mixing Level 25 dB
Room Type Small room
Dynamic Range Compression Film/Standard
Sampling Frequency 48 kHz
Channel Bandwidth Low Pass Filter On
DC High Pass Filter On
RF Protection Off
Surround Mixing Level 3 dB
LFE Low Pass Filter Off
External Delay 179 ms
Audio Musicam (MPEG-2): Bit-rate 384 kbit/s
Coding Mode Stereo
Copyright Off
Original Off
Sampling Frequency 48 kHz
Linear PCM: Linear PCM SMPTE Standard Year 2000
Linear PCM Channel Number 0
RS-422 Data: RS-422 Data Encode Off
RS-422 Data Delay (Option Module) 250 ms
RS-422 Bit-rate 64 kbit/s
PID 0x121, 0x123, 0x125 or 0x127
RS-422 Test Mode (Base Board Only) Off
RS-422 SNMP oid ref. (Base Board Only) 1
RS-232 Data: RS-232 Data Encode Off
RS-232 Data Delay (Option Module) 200 ms
RS-232 Baud Rate 38400
PID 0x120, 0x122, 0x124 or 0x126
RS-232 Test Mode (Base Board Only) Off
RS-232 SNMP oid ref (Base Board Only) 1
