Predefined User Configurations
Instruction Manual: evolution 5000 E5710 and E5720 Encoder Page C-7
ST.TM.E10074.1
C.4 Predefined User Configurations
The predefined user configurations have the same settings as Table C.2
except for those differences shown in Table C.3.
Table C.3: Predefined User Configurations
Configuration Number Service Name Variable Value
1 Auto 2 Mbit/s Video Bit-rate 2 Mbit/s
Video Compression Mode Standard Delay
Video Profile/Level MP@ML
GOP Structure IBBP
2 Auto 4 Mbit/s Video Bit-rate 4 Mbit/s
Video Compression Mode Standard Delay
Video Profile/Level MP@ML
GOP Structure IBBP
3 Auto 6 Mbit/s Video Bit-rate 6 Mbit/s
Video Compression Mode Standard Delay
Video Profile/Level MP@ML
GOP Structure IBBP
4 Auto 8 Mbit/s Video Bit-rate 8 Mbit/s
Video Compression Mode Standard Delay
Video Profile/Level MP@ML
GOP Structure IBBP
5 Auto 15 Mbit/s Video Bit-rate 15 Mbit/s
Video Compression Mode Standard Delay
Video Profile/Level MP@ML
GOP Structure IBBP
6 Very Low Delay 2 Mbit/s Video Bit-rate 2 Mbit/s
Video Compression Mode Very Low Delay
Video Profile/Level MP@ML
GOP Structure IP
7 Very Low Delay 4 Mbit/s Video Bit-rate 4 Mbit/s
Video Compression Mode Very Low Delay
Video Profile/Level MP@ML
GOP Structure IP
8 Very Low Delay 6 Mbit/s Video Bit-rate 6 Mbit/s
Video Compression Mode Very Low Delay
Video Profile/Level MP@ML
GOP Structure IP
9 Very Low Delay 8 Mbit/s Video Bit-rate 8 Mbit/s
Video Compression Mode Very Low Delay
Video Profile/Level MP@ML
GOP Structure IP
10 Very Low Delay 15 Mbit/s Video Bit-rate 15 Mbit/s
Video Compression Mode Very Low Delay
Video Profile/Level MP@ML
GOP Structure IP
