Chapter 2
Usage and Maintenance
The following chapter is an overview of the I™ hardware usage
and maintenance.
2.1 Components
2.1.1 INTERCEPTOR™ Overview
The figure below shows the major components of the I™ and
their locations.
2.1.2 Component Descriptions: Front View
Buttons and LED Bank
The figure below shows the location of the operating buttons and the status
indicating LED bank. The button functions are determined by the opera-
tional modes of the I™. Refer to section 2.3, p. 14 and chapter
3, p. 21 for further information.
1. The left button (denoted “1”) is referred to as the “ ACTION ” button,
and the right button (denoted “6”) as the “ MODE ” button
Thermo Fisher Scientific Interceptor™/en/5.1(4956)/Feb2010 3
